Description
Specifcations
Measurement technology High-precision optical system with high resolution digital
camera and digital image processing
Image capture 1024 x 1024 pixels, 16 million colors, RGB uncompressed
Measurement aperture 1 x 1 mm, direct positioning with viewfnder,
real-time image preview captured in LC graphic device display
Light source Homogeneous spectral-broadband LED illumination
Measurement time Approximately 1 second per measurement
Calibration Factory-made calibrated permanently, white standard in
charging console
Measurement range dot % 0.0 – 100.0 %
Screen ruling range AM: 30 – 150 l/cm, 75 – 380 lpi; FM: 10 – 70 microns
Measurable media Offset printing plates – CtP and conventional,
flm in transmission and reflection, printed paper CMYK
Memory 100 data sets (only Expert and All-Vision)
Repeatability ± 0.5 %
Display Color LC backlight display, anti-reflective, 320 x 240 pixels
Power supply Rechargeable LiFePO4 battery, regulated recharge via charging
console with AC adapter, 100 – 240 V, 47 – 63 Hz, approx. 10000
measurements per battery charge, battery level control
Communication Port USB
Weight 490 grams
Dimensions 61 x 50 x 185 mm (approximately 2.4 x 2.0 x 7.3 inches)
System requirements for TECHKON software:
Windows 7, 8 or 10; 32- and 64-bit, minimum: IBM-compatible PC with Intel Core Duo processor or comparable processor, 4 GB RAM, 2 USB ports
Measurement technology High-precision optical system with high resolution digital
camera and digital image processing
Image capture 1024 x 1024 pixels, 16 million colors, RGB uncompressed
Measurement aperture 1 x 1 mm, direct positioning with viewfnder,
real-time image preview captured in LC graphic device display
Light source Homogeneous spectral-broadband LED illumination
Measurement time Approximately 1 second per measurement
Calibration Factory-made calibrated permanently, white standard in
charging console
Measurement range dot % 0.0 – 100.0 %
Screen ruling range AM: 30 – 150 l/cm, 75 – 380 lpi; FM: 10 – 70 microns
Measurable media Offset printing plates – CtP and conventional,
flm in transmission and reflection, printed paper CMYK
Memory 100 data sets (only Expert and All-Vision)
Repeatability ± 0.5 %
Display Color LC backlight display, anti-reflective, 320 x 240 pixels
Power supply Rechargeable LiFePO4 battery, regulated recharge via charging
console with AC adapter, 100 – 240 V, 47 – 63 Hz, approx. 10000
measurements per battery charge, battery level control
Communication Port USB
Weight 490 grams
Dimensions 61 x 50 x 185 mm (approximately 2.4 x 2.0 x 7.3 inches)
System requirements for TECHKON software:
Windows 7, 8 or 10; 32- and 64-bit, minimum: IBM-compatible PC with Intel Core Duo processor or comparable processor, 4 GB RAM, 2 USB ports
